Single Acting Hydraulic Cylinder

• Capacity: 5-100t
• Stroke: 25-362mm
• Max.pressure: 700bar

• Single-acting,high strength spring return, easy to use.
• The exclusive guide Ring is designed absorbs eccentric loading without galling cylinder parts,reduces wear and extending life.
• Special painted surface to increase corrosion resistance.
• Easy fixturing with collar threads,plunger threads and base mounting holes.
• All models include NPT3/8"-18 quick coupling and dust cap.
• Removable hardened grooved saddles.
• Customizable with special requirement.

• What is the packaging method?                                                          Wooden box packaging
• What is the delivery time?                                                                     Normal products 7-25days.
• Does the product itself support OEM customization?                     We support OEM.
